- Wireless configuration interface via NFC
- Constant power mode design and wide range of output current adjustable: 200mA - 1050mA
- Programmable function with AOC/CLO/EOL
- Autonomous dimming includes three “Smart Timer Dim” operation with Fixed Timer, Midnight Centric Timer, and Ratio Rescale Timer
- Robustness protection against vibration, harsh operating temperature and moisture with potting
- High efficiency design up to 94%
- High surge immunity protection (10K V /6K V)
- Meet dimension criteria of Zhaga Specification
| Model Name |
Phase |
PFC |
Output Voltage |
Output Current |
Output Power |
Input Voltage Range |
Dimensions (L x W x H) |
Download datasheet |
| EUCI-040105GBA |
Phase I |
|
20-77V |
0.2-1.05A |
40W |
198-264Vac |
133 x 77 x 40 mm |
|
| EUCI-075105GBA |
Phase I |
|
35-105V |
0.2-1.05A |
75W |
198-264Vac |
133 x 77 x 40 mm |
|
| EUCI-130105GBA |
Phase I |
|
60-200V |
0.2-1.05A |
130W |
198-264Vac |
150.0 x 90.0 x 40.0 mm |
|
| EUCI-170105GBA |
Phase I |
|
80-310V |
0.2-1.05A |
170W |
198-264Vac |
170.0 x 100.0 x 40.0 mm |
|
